    SDH2104U
    HIGH VOLTAGE HALF BRIDGE DRIVER

        The SDH2104U is high voltage N-type power MOSFET and IGBT half bridge driver, whose built-in undervoltage lockout prevents the power device from working under low control voltage, and high/low side input interlock protection avoids the simultaneous conduction of both high side and low side MOSFETs.

    Main feature

    • High-side floating supply absolute voltage:600V

    • Output current:+0.35A / -0.70A

    • 3.3V / 5V / 15V input logic compatible

    • Built-in dead time

    • Under-voltage (UV) lockout

    • dV/dt immune

    Ordering Information
    Product Name Package form Marking Hazardous Substance Control Packing Type Remarks
    SDH2104U SOP-8-225-1.27 SDH2104U Halogen free Tube
    SDH2104UTR SOP-8-225-1.27 SDH2104U Halogen free Tape&Reel
    Block Diagram


    Documents
    title Types of Size (KB) date Download the latest English version
    SDH2104U 0 1970-01-01 SDH2104U Brief Datasheet
