SDH2106SA
HIGH VOLTAGE HALF BRIDGE DRIVER

The SDH2106DA/SDH2106SA is high voltage N-type power MOSFET and IGBT half bridge driver, whose built-in undervoltage lockout prevents the power device from working under low control voltage, and high/low side input interlock protection is adopted to avoid the simultaneous conduction of both high side and low side MOSFETs.

Main feature

  • High-side floating supply absolute voltage:600V

  • Output current:+0.25A / -0.65Aw  3.3V / 5V / 15V input logic compatible

  • High-/low-side double high input interlock protection

  • Under-voltage (UV) lockout

  • dV/dt immune

Ordering Information
Product Name Package form Marking Hazardous Substance Control Packing Type Remarks
SDH2106SA SOP-8-225-1.27 SDH2106SA Halogen free Tube
SDH2106SATR SOP-8-225-1.27 SDH2106SA Halogen free Tape&Reel
Block Diagram


Documents
title Types of Size (KB) date Download the latest English version
SDH2106 Datasheet 0 1970-01-01 SDH2106 Datasheet_1.2
